Montanari, Liftmachine M98 – M98H by configuration

M98 is a gearbox range for high capacities.

Huge combination of ratios and pulleys, it meets all requirements for installation.

M98 – standard, static load of 7.000 kg
M98H – for high static load without support, static load of 7.000 kg
M98HB – for high static load + auxiliary brake
M98HAL – for high static load + long shaft, static load of 5100 kg
M98HB version has a high static and dynamic load with only two support points. All features meeting the construction needs of the lift industry.

Typical application roping 1:1

1.250 kg 1,6 m/s 520 mm TP 2/49 8 ropes of 13 motor 22 kW
1.600 kg 1 m/s 580 mm TP 1/37 8 ropes of 13 motor 18,5 kW
