Montanari, Liftmachine M83 – M85 by configuration

High number of ratios, suitable for installations up to 10 passengers or for lifting heavy goods.

M83 range reaches up to 4.000 kg of static load and 800 kg of capacity.

M83 – standard, static load of 3.200 kg
M83AL – long shaft, static load of 3.000 kg
M83B – with auxiliary brake
M85 – with support, static load of 4.000 kg
Typical application roping 1:1

800 kg 1,0 m/s 480 mm TP 1/37 5 ropes of 11 motor 9 kW
630 kg 1,6 m/s 520 mm TP 2/50 5 ropes of 10 motor 9 kW
