Montanari, Liftmachine M109 by configuration

15.000 kg of static load and more than 5.000 kg of capacity, M109 is the largest gearbox of the Montanari standard range. Its characteristics and reliability move some of the most important installations in the world. Typical application roping 1:1
1.600 kg 2,5 m/s 700 mm TP 3/58 8 ropes of 13 motor 44 kW
2.000 kg 1,6 m/s 700 mm TP 2/55 8 ropes of 15 motor 37 kW
2.500 kg 1 m/s 650 mm TP 1/49 8 ropes of 15 motor 22 kW
3.000 kg 2 m/s 750 mm TP 2/55 6 ropes of 16 motor 55 kW
It can also be used for goods lifts (cargo) and for cars (vertical car parks or car dealership) roping 2:1 or 4:1.
