Categorie: | Vang Vang systemen |
EC part number: | 20474 |
Brand Compatibility: | for DYNATECH |
Weight | 21.56 kg |
Acting:
UPWARDS AND DOWNWARDS
Guide rail type:
MACHINED
OILED
Minimum gripping width: 25 mm
Admissible guide rail thickness: From 7 to 16 mm
P+Q minimum = 693 Kg (-7,5%)
P+Q maximum = 4233 Kg (+7,5%)
Maximum tripping speed = 2,33 m/s
The eASG-120 UD is an electromechanical bidirectional safety gear consisting of the electromechanical activation DA-UD together with the mechanical safety gear ASG-120 UD
Power supply: 24V
Holding current: 0,32A (0,16 X 2)
Decoupled Coils Option
This option allows for greater control over the system, as you can monitor the status of the reset coil. For further information, please refer to the Manual
According to the standards:
EN 81-20 and EN 81-50.
