Dynatech, ASG-120 UD

Acting:
UPWARDS AND DOWNWARDS

Guide rail type:
MACHINED
OILED

Minimum gripping width: 25 mm
Admissible guide rail thickness: From 7 to 16 mm

P+Q minimum = 693 Kg (-7,5%)
P+Q maximum = 4233 Kg (+7,5%)

Maximum tripping speed = 2,33 m/s

To see the fixations to the sling, consult the T-25 UD driving bar pdf file.

According to the standards:
EN 81-20 and EN 81-50.
