Cobianchi, safety-gear – PC13GO – down – max 2600KG – nose=8mm – trip 0,46m/s – external house

[13GO-O200L09.2A] Pair prog. safety-gear PC13GO
downwards use according to EN 81-20/-50 UCM
with easy release mechanism
compl. assembles, adjusted + sealed
for connection bar outside/limit swicht inside
WITHOUT mounting plate f.width of installation 200 mm
pressure spring + adjustment screw
point of safety rope anchor: LEFT

Basic unit info:
NL08-400-1002-100-02 / Rev. 5
EN81-20/-50 UCM
Contract load: 320.0 kg
Width of guide rail blade: 8.0 mm
Surface of guide rails: machined
Upper surface of rail: oiled
Tripping speed: 0.46 m/s
[13DA-MZ51-1] 2 Cage exterior
[14DA-MZ01-2] 2 Lever outside compl.
[14DA-MZ25-1] Recall springsystem compl. N incl.supp.bolts for recall springsystem
[14DA-MZ45-3b] 2 Retaining plates 200
[FV-MZ30-1] Cable joint assembly
[DA-MZ05-2] Limit switch unlocked
[14DA-MZ38-1] Limit switch mounting angle
[14DA-MZ28-1] Release ring
[DA-MZ17-1] 2 guide rings without releaser
[DA-MZ03-9] connection bar outside, 800 – 1200 mm movable, 800 – 1200 mm
